Product Summary

The IPD15N06S2L-64 is a power transistor.

Parametrics

IPD15N06S2L-64 absolute maximum ratings: (1)Continuous drain current ,ID: 13A; (2)Pulsed drain current, ID,pulse: 76A; (3)Avalanche energy, single pulse, EAS: 43 mJ; (4)Gate source voltage VGS: ±20 V; (5)Power dissipation Ptot: 47 W; (6)Operating and storage temperature Tj, Tstg: -55 to +175℃.

Features

IPD15N06S2L-64 features: (1)N-channel Logic Level - Enhancement mode; (2)Automotive AEC Q101 qualified; (3)MSL1 up to 260℃ peak reflow; (4)175℃ operating temperature; (5)Green package (lead free); (6)Ultra low Rds(on); (7)100% Avalanche tested.

Diagrams

IPD15N06S2L-64 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IPD15N06S2L-64
IPD15N06S2L-64
Infineon Technologies
MOSFET OPTIMOS PWR-TRANS N-CH 55V 19A
Data Sheet
Negotiable
