AT28C64E-15PC

AT28C64E-15PC, Programmable Read Only Memory, DIP, -0.6V to 6.25V, 120ns, 1ms

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: AT28C64E-15PC

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Tom Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-02

From Other Seller

Part Number:AT28C64E-15PC
US $1.00 - 2.00
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT28C64E-15PC is a low-power, high-performance 8,192 words by 8 bit nonvolatile Electrically Erasable and Programmable Read Only Memory with popular, easy to use features. The AT28C64E-15PC is manufactured with Atmel’s reliable nonvolatile technology.

Parametrics

AT28C64E-15PC absolute maximum ratings: (1)Temperature Under Bias: -55℃ to +125℃; (2)Storage Temperature: -65℃ to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4) All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5) Voltage on OE and A9 with Respect to Ground: -0.6V to +13.5V.

Features

AT28C64E-15PC features: (1)Fast Read Access Time: 120ns; (2)Fast Byte Write - 200 ms or 1 ms; (3)Self-Timed Byte Write Cycle: Internal Address and Data Latches, Internal Control Timer, Automatic Clear Before Write; (4)Direct Microprocessor Control: READY/BUSY Open Drain Output, DATA Polling; (5)Low Power: 30mA Active Current, 100mA CMOS Standby Current; (6)High Reliability: Endurance: 104 or 105 Cycles, Data Retention: 10 Years; (7)5V±10% Supply; (8)CMOS and TTL Compatible Inputs and Outputs; (9)JEDEC Approved Byte-Wide Pinout; (10)Commercial and Industrial Temperature Ranges.
