Product Summary

The AT45DB041B-CU is a SPI compatible serial interface Flash memory ideally suited for a wide variety of digital voice-, image-, program code- and data-storage applications. Its 4,325,376 bits of memory are organized as 2048 pages of 264 bytes each. In addition to the main memory, the AT45DB041B-CU also contains two SRAM data buffers of 264 bytes each. The buffers of the AT45DB041B-CU allow receiving of data while a page in the main memory is being reprogrammed, as well as reading or writing a continuous data stream.

Parametrics

AT45DB041B-CU absolute maximum ratings: (1)Temperature under Bias: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V.

Features

AT45DB041B-CU features: (1)Single 2.5V - 3.6V or 2.7V - 3.6V Supply; (2)Serial Peripheral Interface (SPI) Compatible; (3)20 MHz Max Clock Frequency; (4)Page Program Operation: Single Cycle Reprogram (Erase and Program); 2048 Pages (264 Bytes/Page) Main Memory; (5)Supports Page and Block Erase Operations; (6)Two 264-byte SRAM Data Buffers – Allows Receiving of Data while Reprogramming the Flash Memory Array; (7)Continuous Read Capability through Entire Array: Ideal for Code Shadowing Applications; (8)Low Power Dissipation: 4 mA Active Read Current Typical; 2 μA CMOS Standby Current Typical; (9)Hardware Data Protection Feature; (10)5.0V-tolerant Inputs: SI, SCK, CS, RESET, and WP Pins; (11)Commercial and Industrial Temperature Ranges; (12)Green (Pb/Halide-free/RoHS Compliant) Package Options.

Diagrams

AT45DB041B-CU block diagram
